7722HK28 Wheeled Gas Air Compressors

Model 7722HK28 utilizes a powerful two-stage pump to deliver 17.0 CFM @ 90 PSI - enough to keep up with large contracting crews. This model incorporates the popular 270 cc (GX270) Honda engine with automatic idle-down, for increased fuel efficiency, and an atmospheric unloading system to prevent oil consumption.

Optional Equipment: Filter-Regulator-Lubricator Sets, Electric Start

Find a Local Rolair Dealer

Search Dealers

Find an Online Retailer

Shop Now

ABOUT THE PUMP

Heavy-Duty
Two Stage
Cast-Iron Twin Cylinders
Ball Bearings
Splash Lubricated
Cast-Iron Valve Plates with Swedish Lamellar Reed Valves
Aluminum Alloy Connecting Rods with Automotive-Style Inserts
Multi-Finned 15.16" Flywheel
Oil Sight Gauge

ABOUT THE ENGINE

270 cc (9 HP) Honda 4 Cycle
Complete Die Cast Aluminum Alloy with Cast-Iron Sleeve
Overheard Valves
Retractable Starter
On/Off Switch
Splash Lubricated
Low Oil Shutdown

STANDARD EQUIPMENT

Pressure Gauge 0-300 in 5 lb. Graduations
Automatic Pilot Valve Operation
Industrial Flexible Discharge Hose
Automatic Idle Control for Economy and Long Service Life
Intake Filter with Silencer and Replaceable Element
Schmidt Belt Tightening Device
Air-Cooled Aftercooler
Totally Enclosed Steel Belt Guard
Safety Relief Valve

Specifications

Horse Power	270 cc (9 HP)
CFM Displaced	20.3 CFM
CFM Delivered	17.0 CFM @ 90 PSI
Overload Protection	No
Lubrication Type	Splash Lubrication
Pump Oil Capacity	61 oz.
Reed Valve System	Yes (Standard)
Number of Cylinders	2
Tank Capacity	9 Gallons
L X W X H	46"x28"x30"
Decibel Rating	Unavailable
Country Of Origin	Compressor Origin.pdf
Shipping Weight	285 lb.
Shipping Dimensions (L X W X H)	47" x 28" x 36"

Documents

7722HK28 Showroom Sheet

7722HK28 Schematic

7722HK28 Owner's Manual
